| Product Model | Rated Voltage (kv) | Rated Mechanical Bending Load (kn) | Structure Height H. (mm) | Min. Arc Distance (mm) | Min. Creepage Distance (mm) | Diameter of Shed (mm) | Lightning Impulse Withstand Voltage (peak)(kv) | P.F.1min Wet Withstand Voltage (virtual value)(kv) |
| FXB-24/70-EE | 24 | 70 | 425 | 230 | 575 | 98/88 | 125 | 65 |
| FXBW-24/70-SB | 24 | 70 | 440 | 270 | 850 | 130/100 | 125 | 65 |
| FXBW-24/120-SB | 24 | 120 | 545 | 320 | 900 | 115/85 | 145 | 65 |
