| Product Model | Rated Voltage (kv) | Rated Mechanical Bending Load (kn) | Structure Height H. (mm) | Min. Arc Distance (mm) | Min. Creepage Distance (mm) | Diameter of Shed (mm) | Lightning Impulse Withstand Voltage (peak)(kv) | P.F.1min Wet Withstand Voltage (virtual value)(kv) |
| FXBW-11/70-SB | 11 | 70 | 350 | 180 | 420 | 92 | 95 | 45 |
| FXBW-11/100-SB | 11 | 100 | 380 | 185 | 420 | 92 | 95 | 45 |
| FXBW-11/80-SB | 11 | 80 | 450 | 280 | 550 | 144/114 | 125 | 65 |
