| Product Model | Rated Voltage (kv) | Rated Mechanical Bending Load (kn) | Structure Height H. (mm) | Min. Arc Distance (mm) | Min. Creepage Distance (mm) | Diameter of Shed (mm) | Lightning Impulse Withstand Voltage (peak)(kv) | P.F.1min Wet Withstand Voltage (virtual value)(kv) |
| FPQ-33/8 | 33 | 8 | 425 | 320 | 1150 | 122/92 | 230 | 230 |
| FPQ-33/10 | 33 | 10 | 406 | 280 | 940 | 122/92 | 200 | 200 |
| FPQ-33/12 | 33 | 12 | 545 | 380 | 1485 | 200 | 250 | 250 |
| FPQ-33/12.5 | 33 | 12.5 | 545 | 405 | 1650 | 150/120 | 265 | 265 |
