End Fitting for Insulator

End Fitting for Insulator

The metallic end fittings placed at the end of fiberglass rod must have sufficient mechanical features to take the stresses that insulators as subjected to. These terminals can be manufactured in different shapes and materials according to the characteristics requested by the customer or their use.
The mechanical charges of the traction resistance are: 50KN, 70KN, 100KN, 120KN, 160KN, 180KN, 210KN, 240KN.
The models of end fittings that you can use are in the end fitting table here enclosed and they are realized according to the IEC 61466-2 standard.

	Cata No. Suffix	Cata. No.	Breaking Load  （KN）
	B	Ball Eye	50   70   100   120
	S	Socket Clevis	50   70   100   120
	T	Tongue	50   70   100
	C	Clevis	50   70
	E	Eye	70
	Y	YClevis	70
