Name: 6KV Polymer Housed Arrester
No.: S-001
Addtime: 2017-07-05
Views : 14
| Type | Rated Voltage (kV)(rms) | Maximun Continuous Operating Voltage (kV)(rms) | Max. Residual Voltage | 2000μs Square Wave Current Impulse Withstand (A) (crest) | 4/10µ s High current impulse withstand（kA） | ||
| Steep Current Impulse (kv) | 30/60µ s Switching current impulse (kv) | 8/20µ s Lightning current impulse (kv) | |||||
| YH5W-6 | 6 | 5.1 | 19.0 | 15.4 | 18 | 100 | 65 |
| YH10W-6 | 6 | 5.1 | 19.0 | 15.4 | 18 | 250 | 100 |
