Name: 24KV Polymer Housed Arrester
No.: P-006
Addtime: 2017-07-05
Views : 10
immediate inquiry
| Type | Rated Voltage (kV)(rms) | Maximun Continuous Operating Voltage (kV)(rms) | Max. Residual Voltage | 2000μs Square Wave Current Impulse Withstand (A) (crest) | 4/10µ s High current impulse withstand（kA） | ||
| Steep Current Impulse (kv) | 30/60µ s Switching current impulse (kv) | 8/20µ s Lightning current impulse (kv) | |||||
| YH5W-24 | 24 | 19.5 | 76.0 | 61.6 | 72 | 100 | 65 |
| YH10W-24 | 24 | 19.5 | 76.0 | 61.6 | 72 | 250 | 100 |
