Name: 12KV Polymer Housed Arrester
No.: P-004
Addtime: 2017-07-05
Views : 13
| Type | Rated Voltage (kV)(rms) | Maximun Continuous Operating Voltage (kV)(rms) | Max. Residual Voltage | 2000μs Square Wave Current Impulse Withstand (A) (crest) | 4/10µ s High current impulse withstand（kA） | ||
| Steep Current Impulse (kv) | 30/60µ s Switching current impulse (kv) | 8/20µ s Lightning current impulse (kv) | |||||
| YH5W-12 | 12 | 10.2 | 38.0 | 30.8 | 36 | 100 | 65 |
| YH10W-12 | 12 | 10.2 | 38.0 | 30.8 | 36 | 250 | 100 |
